PeraFlex PGP Standard Chemical Composite Hose

Features & Specifications of PeraFlex PGP Standard Chemical Composite Hose

Applications:

• Chemical Carriers, Ship-to-Shore Transfer, In-Plant Service, Rail Tankers
• Resists abrasion, ozone, and fire
• 5 to 1 safety ratio

Tube:

• Seamless polypropylene tubes and film barriers

Reinforcement:

• High-density polyethylene woven fabric with internal polypropylene wire and external galvanized wire

Cover:

• Blue vinyl coated polyester

Temp Range:

• -40°F to +212°F

For more details and to see other hoses like this one, please check out PERAFLEX.COM

Description

Features & Specifications of PeraFlex PGP Standard Chemical Composite Hose

Applications:

• Chemical Carriers, Ship-to-Shore Transfer, In-Plant Service, Rail Tankers
• Resists abrasion, ozone, and fire
• 5 to 1 safety ratio

Tube:

• Seamless polypropylene tubes and film barriers

Reinforcement:

• High-density polyethylene woven fabric with internal polypropylene wire and external galvanized wire

Cover:

• Blue vinyl coated polyester

Temp Range:

• -40°F to +212°F

For more details and to see other hoses like this one, please check out PERAFLEX.COM

Specifications

Part #

I.D

(in.)

O.D

(in.)

Working

PSI

Bend

Radius (in.)

Weight

(lbs/ft)

Standard

Length

PGP100 1 - 200 2.0 .65 80
PGP125 1 1/4 - 200 - - 80
PGP150 1 1/2 - 200 3.0 1.0 80
PGP200 2 - 200 3.5 1.2 80
PGP250 2 1/2 - 200 4.0 2.0 80
PGP300 3 - 200 5.5 2.4 80
PGP400 4 - 200 6.5 3.0 80
PGP600 6 - 200 22.0 7.4 50
PGP800 8 - 200 29.0 12.5 50

Additional information

Diameter

1-1/2", 1", 1-1/4", 2", 2-1/2", 3", 4", 6", 8"
