Applications:
• Pneumatic conveying of grains, powder, pellets, clay, ash, fertilizers, wood chips, drugs, chemicals, corrosive, hot, or abrasive materials, and a variety of other dry products
Tube:
• Extra smooth stainless steel liner 0.015” thickness
Packing:
• Cotton (other packings are available on special order)
Cover:
• Interlocked stainless steel 0.018” thickness
Temp Range:
• -60°F to +1800°F
Applications:
• Pneumatic conveying of grains, powder, pellets, clay, ash, fertilizers, wood chips, drugs, chemicals, corrosive, hot, or abrasive materials, and a variety of other dry products
Tube:
• Extra smooth stainless steel liner 0.015” thickness
Packing:
• Cotton (other packings are available on special order)
Cover:
• Interlocked stainless steel 0.018” thickness
Temp Range:
• -60°F to +1800°F
| Part # |
I.D (in.) |
O.D (in.) |
Working PSI |
Bend Radius (in.) |
Weight (lbs/ft) |
Standard Length |
| SF400KU150 | 1 1/2 | - | 15 | 12.4 | 1.45 | 25 |
| SF400KU175 | 1 /34 | - | 15 | 14.0 | 1.68 | 25 |
| SF400KU200 | 2 | - | 15 | 16.5 | 1.92 | 25 |
| SF400KU225 | 2 1/4 | - | 15 | 17.0 | 2.15 | 25 |
| SF400KU250 | 2 1/2 | - | 15 | 18.1 | 2.37 | 25 |
| SF400KU275 | 2 3/4 | - | 15 | 18.3 | 2.60 | 25 |
| SF400KU300 | 3 | - | 15 | 20.0 | 2.82 | 25 |
| SF400KU350 | 3 1/2 | - | 15 | 21.0 | 3.29 | 25 |
| SF400KU400 | 4 | - | 15 | 22.5 | 3.75 | 25 |
| SF400KU450 | 4 1/2 | - | 15 | 24.8 | 4.21 | 25 |
| SF400KU500 | 5 | - | 15 | 26.9 | 4.68 | 25 |
| SF400KU600 | 6 | - | 15 | 31.0 | 5.59 | 25 |
| SF400KU700 | 7 | - | 15 | 32.5 | 6.52 | 25 |
| SF400KU800 | 8 | - | 15 | 36.0 | 7.74 | 25 |
| SF400KU1000 | 10 | - | 15 | 50.0 | 9.65 | 25 |
| SF400KU1200 | 12 | - | 15 | 60.0 | 11.65 | 25 |
| Inner Diameter | 1-1/2", 1-3/4", 2", 2-1/4", 2-1/2", 3", 3-1/2", 4-1/2", 4", 5", 6", 7", 8", 10", 12" |
|---|
