CONTITECH FABCHEM

CHEMICAL HOSE

Call for price
Categories: , ,

Download:   Catalog

Description

Applications:
• This hose handles the majority of common industrial chemicals in pressure, gravity flow and suction services.

Tube:
• Pliosyn UHMW

Reinforcement:
• Spiral-plied synthetic fabric with double wire helix

Cover:
• Green Versigard synthetic rubber with bright orange longitudinal stripe, corrugated (wrapped impression)

Temp Range:
• -40°F to +150°F

Specifications

Part #

I.D

(in.)

O.D.

(in.)

Working

PSI

Bend

Radius (in.)

Weight

(lbs/ft)

Standard

Length

GFC100 GFC100SBQ 1 1.53 200 5.0 .72 150
GFC125 GFC125SBQ 1 1/4 1.88 200 8.0 .86 100
GFC150 GFC150SBQ 1 1/2 2.13 200 8.0 .89 150
GFC200 GFC200SBQ 2 2.63 200 9.0 1.13 150
GFC300 GFC300SBQ 3 3.63 150 16.0 1.64 150
GFC400 GFC400SBQ 4 4.69 150 21.0 2.39 100

Additional information

Diameter

1", 1-1/4", 1-1/2", 2", 3", 4"
