Application:
Tube:
Ultra high molecular weight polyethylene (U.H.M.W.)
Reinforcement:
Textile, 2 ply and helical wires
Cover:
Green Corrugated EPDM
Temp Range:
-45°F to +220°F
Application:
Tube:
Ultra high molecular weight polyethylene (U.H.M.W.)
Reinforcement:
Textile, 2 ply and helical wires
Cover:
Green Corrugated EPDM
Temp Range:
-45°F to +220°F
|
Part # |
I.D. (in.) | O.D. (in.) | Working PSI | Bend Radius (in.) | Weight (lbs/ft) | Standard Length |
| OHSUH150 | 1-1/2" | 2.13" | 200 | 4.0 | .89 | 135, 150 |
| OHSUH200 | 2" | 2.63" | 200 | 5.0 | 1.16 | 135, 150 |
| OHSUH300 | 3" | 3.63" | 200 | 6.5 | 1.68 | 135, 150 |
| OHSUH400 | 4" | 4.68 | 150 | 9.5 | 2.26 | 135, 150 |
